- Package Includes: (1) DBX ZonePro 640 Commercial/Restaurant 6 In / 4 Out Matrix Digital Zone Processor. (1) DBX ZC1 Wall Mounted Programmable Zone Controller For DriveRack and ZonePro ZC 1. Advanced Feedback Suppression (AFS ). Autowarmth . Auto Gain Control. Compression. Limiting. Noise Gating. Notch Filtering. Bandpass and Crossover Filters. Parametric EQ. Security Lockout. Wall Panel Control. RS-232 Control. Windows 2000 and XP GUI. IEC, UL and CSA Approvals
- Input: (6 total) (2) Switchable line or mic inputs (4) RCA Source. Input Connectors: Euroblock (Line and Mic) RCA (Source). Input Type: Electronically balanced/RF-filtered. Input Impedance: 50k ohm balanced, 75k ohm unbalanced. Max Input: 20dBu Mic/Line, 12dBu RCA. CMRR: 40dB, typically 55dB @ 1 kHz. Mic Preamp gain: 30 to 60dB. Mic Preamp Equivalent Input Noise (EIN): -118dB. Mic Preamp Phantom Power: 15V. Output: 4 total. Output Connectors: Euroblock
- Output Type: Electronically Balanced, RF Filtered. Output Impedance: 120 ohms balanced, 60ohm unbalanced. Max Output: 20dBu. A/D Converter: dbx Type IV conversion system. A/D Dynamic Range: (line) 113 dB, A-weighted, 110 dB unweighted. Type IV Dynamic Range: 119dB, A-weighted, 22kHz; BW: 117dB, unweighted, 22kHz BW. Digital Output: RCA 24-Bit oversampling. Digital Output Dynamic Range: 114 dB A-weighted, 110dB unweighted. Sample Rate: 48kHz
- Output Type: Electronically Balanced, RF Filtered. Output Impedance: 120 ohms balanced, 60ohm unbalanced. Max Output: 20dBu. A/D Converter: dbx Type IV conversion system. A/D Dynamic Range: (line) 113 dB, A-weighted, 110 dB unweighted. Type IV Dynamic Range: 119dB, A-weighted, 22kHz; BW: 117dB, unweighted, 22kHz BW. Digital Output: RCA 24-Bit oversampling. Digital Output Dynamic Range: 114 dB A-weighted, 110dB unweighted. Sample Rate: 48kHz
- Safety Agency Certifications: UL 600065, IEC 60065, EN 55013, E60065. Specifications: Connectors: (2) RJ-45. Series Wiring: Maximum Cable Length varies with number of Zone Controllers. For Example,Three Zone Controllers: 600 ft. Six Zone Controllers: 300 ft. Parallel Wiring using ZC-BOB: Up to Six Zone Controllers: 1000 ft. Parallel Wiring Cable: CAT5 or CAT5E with 28.6 Ohm/M (Ohm/1000ft.) nominal DCR and rated VW-1 or higher.
Safety Agency Certifications: UL 60065, IEC 60065, EN 55013, E60065 With 6 inputs and 4 outputs the dbx ZonePRO 640 provides flexible signal routing, powerful DSP processing and multiple control interfaces for Commercial Audio applications.Designed to offer superior system sonic performance and flexibility, the 640/641 deliver the highest quality tools available. Even the input and outputs connectors were chosen for their standard usage and reliability. The ZonePRO products offer Euroblock connectors for balanced signals and RCA connectors for interfacing with consumer equipment often used in commercial applications; there is also a simple analog input buss that allows inputs to be sent from one unit to the next for unit and job scalability. The 640 and 641 provide every necessary processing tool, from the input processing like gain control and EQ available on all inputs to highly sophisticated and specific functions such as selectable paging microphone processing including Gating, De-Essing, Auto Gain Control, Compression and Feedback Suppression. The Zone Controllers offer extended utility to the DriveRack and ZonePRO families. The nine Zone Controllers use analog DC voltage to provide logic control ranging from zone source selection, volume and muting, to program or scene selection and fire safety muting. Wired with readily available and affordable CAT5 cable with universally accepted RJ-45 connectors at distances up to 1000 ft, the ZC Zone Controllers offer simple yet elegant solutions to the contractor.The ZC-1 provides programmable remote volume control for the DriveRack 220i, 260 and ZonePRO devices.
