- 【Enhanced Precision and Efficiency】Experience superior measurement accuracy with a 24-bit resolution and dual input options, perfect for various sensor applications. Enjoy low power consumption with just 120 μA in duty cycle mode, for battery-operated devices.
- 【Versatile Sensor Compatibility】Seamlessly integrate with multiple sensor types including RTDs, thermocouples, thermistors, and pressure sensors. Our ADS1220 is designed for flexibility in industrial and portable instrumentation.
- 【Robust Build and Reliable Performance】Operate confidently across a wide temperature range (-40°C to 125°C), with a durable design that withstands environments. Features like a 2.048-V internal reference and a precision oscillator enhance stability and reliability.
- 【Streamlined Connectivity】Simplify your setup with our SPI compatible interface, ensuring easy integration into your existing systems. The internal PGA allows for high input impedance and gain adjustments, accommodating a variety of signal types.
- 【Compact and Cost-Effective】Reduce system costs and space with our integrated features in a compact VQFN-16 or TSSOP-16 package,for factory automation, process control, and consumer electronics.
1. Product Characteristics
Low current consumption: as low as 120 μA (typical) in duty cycle mode
Power supply range:3V~5 V
Up to 20-bit effective resolution with two differential or four single-ended inputs
Dual matched programmable current sources: 10 µA to 1.5 mA
Internal 2.048-V reference: 5 ppm/°C (typical) drift
Internal 2% precision oscillator
Internal temperature sensor: 0.5°C (typical) accuracy
SPI compatible interface (mode 1)
2. Product Applications
Temperature Sensor Measurement.
W1G Electro7
YouXin Electroni!
-Thermistor
-Thermocouple
Resistance Temperature Detectors (RTD): 2, 3 or 4 wire type 2 wire bridge Sensor Measurement: -Pressure Sensor
-Pressure transducers
-Strain Gauges
-Scales
Portable Instruments
Factory automation and process control
3.Description
The ADS1220 is a precision 24-bit analogue-to-digital converter (ADC) that provides a number of integrated features to reduce system cost and part counts for measuring small sensor signals.
The device implements two differential or four single-ended inputs via a flexible input multiplexer (MUX), whisper, programmable gain amplifier (PGA), two programmable excitation current sources, a voltage reference, an oscillator, a low-side switch, and a precision temperature sensor.
The device can convert at a data rate of 2000 samples per second (SPS) with single-cycle settling. At 20 SP, digital filters provide simultaneous 50 Hz and 60 Hz rejection for noisy industrial applications.
The internal PGA provides high gain to 128 V/V.
The PGA makes the ADS1220 ideally suited for applications that measure small sensor signals such as resistance temperature detectors (RTDs), thermocouples, thermistors, and resistance bridge sensors.
- Product Dimensions : 7.08 x 4.72 x 0.7 inches; 0.28 ounces
- Date First Available : August 23, 2022
- Manufacturer : JESSINIE
- Country of Origin : China
