Main
| Range of product | Modicon M238 logic controller |
| Product or component type | Discrete output module |
| Discrete output number | 32 |
| Discrete output type | Transistor |
| Discrete output voltage | 24 V |
| Discrete output logic | Source |
| Discrete output current | 0.4 A |
Complementary
| Range compatibility | Advantys OTB Twido |
| Output voltage limits | 20.4...28.8 V |
| Current per channel | 0.48 A |
| Maximum current per output common | 2 A |
| Number of common point | 2 |
| Response time | 450 µs from state 0 to state 1 450 µs from state 1 to state 0 |
| [Ures] residual voltage | 0.4 V at state 1 |
| Maximum leakage current | 0.1 mA |
| Maximum inductive load | 10 mH |
| Maximum tungsten load | 9.6 W |
| Short-circuit protection | With automatic reactivaton |
| Overload protection | With automatic reactivaton |
| Isolation between channels | None |
| Isolation between channels and internal logic | 500 V for 1 minute |
| Current consumption | 25 mA at 5 V DC at state 1 for all output 40 mA at 24 V DC at state 1 for all output |
| Local signalling | 2 display blocks |
| Electrical connection | 1 connector HE10 |
| Mounting support | 35 mm symmetrical DIN rail |
| Net weight | 0.105 kg |
Environment
| Depth | 81.3 mm |
| Height | 90 mm |
| Width | 33.5 mm |
Offer Sustainability
| Sustainable offer status | Green Premium product |
| REACh Regulation | |
| REACh free of SVHC | Yes |
| EU RoHS Directive | Pro-active compliance (Product out of EU RoHS legal scope) |
| Mercury free | Yes |
| RoHS exemption information | |
| China RoHS Regulation | |
| Environmental Disclosure | |
| Circularity Profile | |
| WEEE | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins |
Contractual warranty
| Warranty | 18 months |
